LAUNCH® X431 PAD V 12V 24V Car All Systems Online Programming Diagnostics Tool

Save $500.00

Sale price$2,999.00 Regular price$3,499.00


✅2021 Latest High-end Comprehensive Car Diagnostic Tool: X-431 PAD V is equipped with the new SmartBox 3.0 diagnostic box, which supports the diagnosis of passenger cars(12V), commercial vehicles(24V), new energy vehicles, and has the characteristics of wide coverage, strong diagnostic functions, and accurate test data.
LAUNCH X431 PAD V  ECU Bi-Directional Online Programming Diagnostic Tool
✅2021 Hardware Upgrade: 10.1-inch sun-visible screen, 2.4GHz / 5GHz dual-band WIFI, 64GB storage (up to 128GB expansion), 8-core 2.0GHz CPU, 9360mAh supports QC3.0 fast charge, front 800W, rear 1300W camera, with charging dock station, resolution up to 1920x1200. X431 PAD V features a smart box, providing a faster dual Wi-Fi vehicle and 5G network communications.
LAUNCH X431 PAD V  ECU Bi-Directional Online Programming Diagnostic Tool
✅Online Programming+Active Testing+Key Procedures: Online coding can help you re-match, re-learn, and re-code a new ECU. Two-way control/active test to request information or command the actuator to perform specific tests. If you know the password, this startup scanner can add a new key to the car.
LAUNCH X431 PAD V  ECU Bi-Directional Online Programming Diagnostic Tool
✅33+Reset Service(26 free and 7 can be purchased, not buying additional 7 paid functions will not affect the use):  SAS,BRAKE,GEAR,OIL,IMMO,INJEC,TPMS,BMS,BLEED,ETS,DPF,SUS,AFS,SUN,GEARBOX,EGR, Language Change,A/F,Coolant Bleed, NOx Sensor,Seats Calibration,Stop-Start,Transport Mode,Tyre Reset,Windows Calibration,AdBlue Rest,A/C relearn, Intelligent cruise control, Engine power balance monitoring, Motor angle calibration, High voltage battery diagnostic, GPF regeneration, Key program.(The last 7 functions need to be purchased to use)
LAUNCH X431 PAD V  ECU Bi-Directional Online Programming Diagnostic Tool
✅24 Languages: Support English, German, Italian, French, Polish, Dutch, Spanish, Portuguese, Hungarian, Greek, Swedish, Finnish, Danish, Czech, Persian, Romanian Text, Serbian, Turkish, Japanese, Korean, Arabic, Russian, Chinese (S&T), Thai.
LAUNCH X431 PAD V  ECU Bi-Directional Online Programming Diagnostic Tool
✅Powerful Data Display + Additional Features: The x431 v pad supports ADAS, small Wifi printer, oscilloscope, sensor multimeter, battery test, endoscope and ignition analysis module. (Not contained in the package)

LAUNCH X431 PAD V  ECU Bi-Directional Online Programming Diagnostic Tool

 🤔How about a warranty and update?

 🥳5 Years Warranty + 1 Year Free Update

1. Models supported by online programming: Audi, BMW, Porsche, Mercedes-Benz, Volkswagen, Land Rover, Nissan, Skoda, SEAT, Subaru, Infiniti.(Please tell me your model before buying, we will check whether your model can be programmed!)

2. Currently, the United States, Spain, Mexico, Canada can only support Infiniti and Nissan programming functions.

Product Advantages:
1. The host and the diagnostic connector adopt 5G Wi-Fi communication, which is far superior to Bluetooth in terms of transmission rate, diagnostic distance, and anti-interference.
2. Supports automatic vehicle identification through VIN, quick access to the vehicle system, and historical diagnosis record query.
3. Support J2534/RP1210/D-PDU diagnostic standards, and can be used alone with part of the original diagnostic software.
4. Support full-system, full-OBDII functions, Deep Diagnosis Your Vehicles, access to ALL vehicle systems and subsystems, to perform a comprehensive scanning on ECUs.
5. The protection grade is IP65, which is more waterproof and resistant to fall.
6. The four corners of the product are equipped with soft rubber protection to effectively prevent a collision.
7. The damping shaft can be adjusted by 180 degrees and supports three modes: lifting, supporting and normal.
8. Rich interfaces, USB Type C (charging and file transfer), USB Type A (module expansion interface), TF slot (extended TF card slot), SIM slot (SIM card slot)
9. It supports ADAS system calibration and needs to be used with X-431 ADAS PRO products.
10. Web-based remote diagnosis can realize real-time communication between mobile phones or computers and equipment to complete vehicle remote diagnosis, and the network broadband and system resource occupancy rate is low.
11. Support one-key upgrade of the operating system, client, model software and firmware.

Operating system: Android 7.1
CPU: Qualcomm MSM8953 2.0GHz eight-core
Memory: 4GB
Storage: 64GB (up to 128GB expansion)
Display screen: 10.1 inches, fully fit, sunlight-readable screen
Resolution: 1920x1200
Touch screen: IPD touch screen
Camera: the first 8 million pixels, the rear 13 million pixels
Wi-Fi: Support 2.4GHz&/5GHz dual-frequency x2
Working temperature: 0℃~50℃
Size: 320mm*211mm*46mm

SmartBox Diagnostic Connector Parameters:
CPU: Dual-processor Cortex-A7+Cortex-M7
Operating System: Linux
Working voltage: DC 9V ~ 36V
Memory: 256M
Storage: 8GB
USB: Type B x 1
Wi-Fi: 2.4GHz&5GHz dual frequency
Working temperature: 0℃ ~ 50℃

Size: 200mm*75mm*40mm


Package List:
1 * LAUNCH Pad V
1 * User Manual
1 * Heavy Truck Module
1 * OBDI Power Cord
1 * OBDI Adapter Cable
1 * Packing box

1 * Base
28 * Connector Tool

Payment & Security


  • Can It program honda car with new software

    Sorry sir, X431 Pad V currently does not support Honda programing!
